60Amp 120/240VAC 10kA 3-Pole General Electric Q-Line THQL Series Molded Case Circuit Breaker
gedthql32060
60Amp 120/240VAC 10kA 3-Pole General Electric Q-Line THQL Series Molded Case Circuit Breaker
Price
$181.15
/ EA
Inventory
Available for delivery
Unavailable for pick up
Abbotsford
Manufacturer:DEALER SOURCE INC.
Manufacturer #:THQL32060
Description
THQL Moulded case/Q-line/plug-in circuit breaker. 60 A, 3-pole. 240 VAC system voltage. Non-interchangeable trip style. LI trip function. Q-line frame type. Standard continuous current rated. Suitable for reverse feed. 8 to 3 KCMIL (copper) or 8 to 3 KCMIL (aluminium) wire range, solid or stranded for 14 to 10 AWG. Fixed long time and instantaneous. HACR special marking. Q-line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications. The QL breakers are plug-in versions of the Q-line used for connection to load centers and lighting panels. All Q-line circuit breakers feature quick-make or quick-break mechanisms, common trip bars and easy to spot trip indication to ensure safety and reliability. Internal common trip.
Specifications
| Brand Name | Emerson | Item Name | Molded Case Circuit Breaker |
| Type | Type THQL, Internal Common Trip | Number of Poles | 3 |
| Interrupt Rating | 10 kA | Amperage Rating | 60 A |
| Voltage Rating | 120/240 VAC | Terminal Connection | Lug |
| Mounting Type | Plug-in | Phase | 3 |
| Frequency Rating | 50/60 Hz | Conductor Size | 8-3 AWG Copper, 8-3 AWG Aluminum |
| Frame | Q-Line | Trip Type | Non-Interchangeable, Thermal Magnetic |
| Dimensions | 3-9/32 in L x 3 in W x 2-3/8 in D | Standards | UL File E11592, HACR Rated |
| Application | For Load Centers and Lighting Panels |
Packages
| 1 - UNIT - 1 | 3 - UNIT - 3 |
