ABB TG3224 200Amp 240V 2 Pole Spec-Setter™ Safety Switch, NEMA 1
gedtg3224
ABB TG3224 200Amp 240V 2 Pole Spec-Setter™ Safety Switch, NEMA 1
Price
$536.72
/ EA
Inventory
Available for backorder
Unavailable for pick up
Abbotsford
Manufacturer:ABB
Manufacturer #:TG3224
Description
General duty fusible switch. 100 A, 240 VAC, 2-pole. 3-wire system. NEMA type-3R (outdoor) enclosure. 10 to 1/0 AWG (copper/aluminium) wire range. 7 or 15 HP at 240 VAC (1 or 3-phase) NEC standard. 15 or 30 HP at 240 VAC (1 or 3-phase) time delay. 20 HP at 250 VDC. Designed for residential and light commercial applications where duty is not severe. Listed to UL standard 98 enclosed and dead front switches. Suitable for use as service equipment when installed in accordance with the National Electrical Code. Meets or exceeds NEMA KS1 standard for enclosed switches type GD. Quick-make, quick-break mechanism (30 to 200 A). 60/75°C conductor rating.
Specifications
| Brand Name | GE | Sub Brand | Spec-Setter™ |
| Item Name | Disconnect Safety Switch | Type | Fusible, General Duty |
| Voltage Rating | 240 VAC | Amperage Rating | 200 A |
| Phase | 1 | Load Rating | 15 hp at 240 VAC Standard, 15 hp at 240 VAC Time Delay 1PH |
| Fuse Type | Cartridge, Class R | Interrupt Rating | 100 kA at 240 V |
| Number of Poles | 2 | Number of Wires | 3 |
| Wire Size | 2 AWG - 250 kcmil | Series/Model | TG |
| Frequency Rating | 50/60 Hz | Housing Material | Steel |
| Mounting Type | Surface | NEMA Rating | NEMA 1 |
| Temperature Rating | 60 - 75 °C | Dimensions | 13.4 in W x 29.11 in H x 5.2 in D |
| Application | For Residential or Light Commercial Application | UPC | 783164008555 |
Packages
| 1 - UNIT - 1 |
